14x6 & 175/70R14 LT RA1100 HQ Holden Rocket Trailer Caravan Mag Wheel Rim & All Terrain Tyre

14x6 HQ HOLDEN 5 STUD ROCKET ALLOY MAG WHEEL
FITTED WITH BRAND NEW 175/70R14 LT TYRE
10 PLY RATING, LOW PROFILE


PCD: 5/120.65
0FFSET: 0
CENTRE BORE: 84MM
REAR OFFSET: 90MM (WITH TYRE FITTED)
WHEEL RATING: 997KG EA
COMES WITH CENTRE CAP AND DECAL

TYRE SIZE: 175/70R14
TYRE USE: LIGHT TRUCK
SPEED CATEGORY SYMBOL: S
LOAD INDEX: 98/96
KG RATING: 750KG PER TYRE
PLY RATING: 10 PLY
DIAMETER: 602MM

MAX LOAD 750KG PER WHEEL AND TYRE

OFFSET +15
(this is the offset wheel trailer manufactures allow for axle lengths so for replacement trailer and caravan wheels this is the offset required. A neutral 0 offset wheel will generally push the tyre bulge outside of guards. This dosn't put unnecessary pressure on bearings)

HOW DO I KNOW WHICH STUD PATTERN I HAVE?
"MEASURE FROM CENTRE OF ONE STUD TO CENTRE OF THE NEXT STUD"
64MM = HT HOLDEN
68MM = FORD
70MM = HQ

PRICE IS PER WHEEL AND TYRE

AT TIME OF FITTING TYRE IS INFLATED TO 40PSI.
